GanttChart

Overview

GanttChart is a powerful C# library designed for creating and managing Gantt charts in your applications. It provides an intuitive API for creating projects, tasks, and visualizing project timelines.

Getting Started

To get started with GanttChart, follow these simple steps:

Installation

Clone the repository and build the solution:

git clone https://github.com/jakesee/ganttchart.git
cd ganttchart
# Open GanttChart.sln in Visual Studio and build

Basic Usage

Create Chart and Adding Tasks

public Form1()
{
    InitializeComponents();
    var manager = new ProjectManager();
    var task = new Task() { Name = "Hello World" };
    manager.Add(task);
    var chart = new Chart();
    chart.Init(manager);

    this.Controls.Add(chart);

}

Common Task Manipulation

You can manipulate the task through code using various methods in the ProjectManager:

// Set task durations
_mManager.SetDuration(wake, 3);
// Give the Tasks some organisation, setting group and
// precedents e.g. make "wake" task a subtask under "work"
_mManager.Group(work, wake);
// Setting task dependencies e.g. make "wake" task a precedent of "brush teeth" task
_mManager.Relate(wake, teeth);
// Assigning Resources e.g. add "jake" resource to "wake" task
_mManager.Assign(wake, jake);
// splitting a tasks e.g. split the "pack up" task into 2 new tasks
_mManager.Split(pack, new MyTask(_mManager), new MyTask(_mManager), 2);
// set some tooltips to show the resources in each task
// e.g. set a tooltip on the "wake" task
_mChart.SetToolTip(wake, string.Join(", ", _mManager.ResourcesOf(wake).Select(x => (x as MyResource).Name)));

Custom Task Data: Different colors for every tasks

You can change the default task appearance for all task, or as in here change individual task color as a demo for adding custom business data to tasks.

public partial class ExampleSimple : Form
{
  ProjectManager _mProject;
  public ExampleSimple()
  {
    InitializeComponent();
    _mProject = new ProjectManager();
    _mProject.Add(new Task() { Name = "New Task" });
    _mProject.Add(new ColoredTask() { Name = "Purple Task", Color = Color.Purple });
    _mProject.Add(new ColoredTask() { Name = "Gold Task", Color = Color.Gold });
    _mChart.Init(_mProject);
    // Custom behavior on paint task
    _mChart.PaintTask += (s, e) =>
    {
        ColoredTask ctask = e.Task as ColoredTask;
        if (ctask != null)
        {
            var format = new TaskFormat();
            format = e.Format;
            format.BackFill = new SolidBrush(ctask.Color);
            e.Format = format;
        }
    };

    // Grab custom data for tasks
    _mChart.TaskSelected += (s, e) =>
    {
        ColoredTask ctask = e.Task as ColoredTask;
        if (ctask != null)
        {
            MessageBox.Show("Selected " + ctask.Color.ToString());
        }
    };
  }
}

// Custom task with business data
public class ColoredTask : Task
{
    public ColoredTask() : base() {}
    public Color Color { get; set; }
}

Documentation

Comprehensive documentation is available including:

• Auto-generated API documentation (Doxygen)
• Code examples in the GanttChartExample project
• Unit tests in the GanttChartNUnitTests project

Examples

The repository includes example projects demonstrating various features:

• ExampleSimple.cs - Basic usage patterns
• ExampleFull.cs - Advanced features and customization

Run the GanttChartExample project to see these examples in action.

API Reference

The main classes in the GanttChart library include:

• Chart - The main chart component
• Project - Represents a project with tasks
• IProject - Interface for project implementations
• Viewport - Handles chart viewport and scrolling

For detailed API documentation, please refer to the generated documentation.
